Pressure relief valve Dn250

Product Categories

BEIJING SONGTIANCHENG TECHNOLOGY

Contact Now

Name: Pressure relief valve Dn250
Brand: BJSTC
Price: 650 USD

Brand Name : BJSTC

Model Number : Dn250

Certification : Quality Managment System Certification

Place of Origin : China

MOQ : 1

Price : $650

Payment Terms : T/T, Western Union, L/C

Supply Ability : 1000000/per month

Delivery Time : within 7 working days

Packaging Details : carton

Name : PE Vavle fro gas appliaction

Standard Complicance : GB/t 15558.4-2002 Buried polyethylene (PE) piping systenm for the supply of gaseous fules-part4:Valves

Raw Material Grade : PE100

DN : dn250

Standard Dimension : SDR 11

Max Operating Pressure : 0.8 Mpa

Applicable Temperature Range : -20℃~40℃

Applicable Medium : Gas

Medium flow ditection : Bi-directional valve

Fluid flow characteristics : Full bore valve

Manufacture : Beijing Songtiancheng Technology Co.,Ltd

Contact Now

Pressure relief valve Dn250

Dn250 overview

d_n	D_1,min	D_1,max	D2	E_min	E_max	L	L1	L2	H	H1	H2	w	WEIGHT(Kg)
250	250	251.5	194	22.7	25.1	890	195	145	1210	997	871	413	60.8

Instruction for Use

The tubular section of the valve can be connected to pipes conforming to GB/T 15558.2-2023 and pipe fittings conforming to GB/T 15558.3-2023D. The connection shall be carried out in accordance with the relevant requirements of Chapter 5 "Pipe Connection" in the CJJ63-2018 .
The valve should be unpacked before connecting to the pipeline. After unpacking, confirm that the valve has a good appearance, operates normally, and verify that the valve model and the parameters listed on the identification match the design requirements.

Pressure relief valve Dn250 Images
